1. Main functions and features
Passive Detection : Able to identify UAV such as DJI and AUTEL that use OFDM
high-definition image transmission; Can detect FPV using analog image transmission within 300MHz-6200MHz.
Sound and light alarm: headphone sound alarm, external sound and light alarm.
Log recording: It has alarm log recording and can export alarm logs through USB interface.
Headphone function: capable of obtaining alarm sound through headphones. Firmware upgrade function: Upgrade firmware through USB interface.
Data transmission function: Real time alarm data of the drone can be obtained through the USB port.
Multi language switching: supports English and Russian. Work status display: language, battery level
Working modes: default mode, key frequency band scanning mode, user-defined feature library scanning mode.
Custom detection: Users can modify, delete, or add detection drone feature libraries through the USB interface.
2. Technical indicators
Receiving frequency range: 300MHz-6200MHz
Identification type: OFDM high-definition image transmission signal, time traveling machine FM analog image transmission
Detection distance: ≥ 1km
Detection sensitivity: better than -96dBm
Alarm detection methods: headphones, sound and light Log recording: Supports no less than 500 alarm records Upgrade and data export interface: mircoUSB
Power supply: Removable lithium battery (type-c charging)
Battery type: 2400mA lithium battery Battery life: ≥ 6 hours (single battery)
Structural dimensions: ≤ 135mm × 60mm × 35mm (host without antenna) Working weight: ≤ 500g (including single battery)
