Direct digital synthesis (DDS) is a method of using digital technology to
generate high-precision, high-resolution analog signals (usually sine waves). It has the
characteristics of high-resolution frequency synthesis, fast frequency switching,
high-resolution phase control, phase continuity, and wide frequency range
1 Function and application
Direct digital synthesis (DDS) is a method of using digital technology to
generate high-precision, high-resolution analog signals (usually sine waves). It has the
characteristics of high-resolution frequency synthesis, fast frequency switching,
high-resolution phase control, phase continuity, and wide frequency range.
1.1 Product Features
1) Full frequency band coverage
Supports 100MHz~6GHz, maximum bandwidth 300MHz, frequency and
bandwidth can be configured through commands.
2) Multiple modulation
Support ASK\FSK\PSK modulation mode.
3) Instruction Configuration
Sweep interval and dwell time can be configured via commands.
4) Output power adjustable
Output power is adjustable, adjustment range is 30dB.
1.2 Parameters
Environmental Specifications
PARAMETER
UNIT
RATING
SYMBOL
Operating Case Temperature
°C
-20~85
T
C
Storage Temperature
°C
-40~85
T
STG
Relative Humidity(Non-condensing)
RH
95
%
