Item |
Spec. |
Remarks |
|
|
Frequency Range |
1100-1700 MHz |
|
|
|
Working Voltage |
28V |
-- |
|
|
Output Power (Max) |
≥43 dBm@80%
|
||
|
Ripple in Band |
≤ 10dB |
Peak |
|
|
Enable control |
Customize |
5V |
|
|
temperature protection |
Turn off the amplifier at 80 ℃ |
|
|
|
Input VSWR |
≤1.5 |
|
|
|
Output VSWR |
≤3 |
|
|
|
High Low Temperature test |
Working Temperature |
-20～+85℃ |
Working properly |
|
Gain Stability |
±1 dB |
at -20℃～+55℃ |
|
|
Power stability |
±1 dB |
at -20℃～+55℃ |
|
|
Working current |
≤1.5A @+28V dc； |
CW output 100W |
|
|
Power supply Port |
7W2 |
28V; GND |
|
|
Monitor Port |
7W2
|
Enable control |
|
|
temperature alarm |
|||
|
|
|||
|
LED indicator light |
Power ON/OFF |
|
|
|
Dimension |
150*80*23 mm |
|
|
|
Installation Dimension |
144.5*74.5*23 mm |
|
|
|
Screw Size |
4-Ø3.20 mm |
|
|
|
Weight |
590g |
||
