Features:
1. Cost effective solution for weak signal zones, reduce drop/off calls.
2. Compact size, low power consumption, easy installation, great cover. Expansion and extention of the signal of base station.
Optimization of the quality of the signal and source
3. Cover about 500~3000m² without block or obstruct.
4. High linear design, ALC function design, low interference to BTS.
5. Support any cellular devices (voice & data & video)
6. Wide band signal booster, or customize selective band booster.
7. Support system CDMA450, LTE800, iDEN, CDMA800, GSM, EGSM, AWS1700,
DCS,PCS,WCDMA, LTE2600,etc
Application:
To expand signal coverage or fill signal blind area where signal is weak or unavailable.
· Indoor: Hotels, exhibition centers, basements, shopping malls, offices, parking lots.
| Working Frequency (customizable) | Uplink | 890~915MHz 1710-1785MHz |
| Downlink | 935~960MHz 1805-1880MHz |
|
| Working Ba
|
Customizable | |
| Output Power (customizable) | Uplink≥ 0dBm, Downlink 20dBm | |
| Gain | Uplink ≥25dB, Downlink ≥ 30dB | |
| Manual Gain Control | 31dB / 1dB Step | |
| Automatic Gain Control | >20dB | |
| Voltage Standing Wave Ratio (VSWR) | < 1.5 | |
| Noise Figure | ≤ 6dB | |
| In-Band Ripple | ≤ 6dB | |
| Frequency Error | ≤ 0.05ppm | |
| Spurious Emission | Within working band | ≤ -15dBm/30kHz |
| Out of working band (Δf > 2.5MHz) |
9kHz~1GHz: ≤ -36dBm/30kHz | |
| 1GHz~12.75GHz: ≤ -30dBm/30kHz | ||
| Return lose | ≤- 10dB | |
| Time Delay | ≤ 1.5μSec | |
| I/O Impedance | 50Ω | |
| RF Connector | N-Type (Female) | |
| Temperature Range | Operation: -10ºC~55ºC | |
| Relative Humidity Range | ≤ 95% (non condensing) | |
| Power Supply (customizable) | AC100-240V,50/60Hz; DC9V/3A | |
| Power Consumption | ≤200W | |
| Dimensions(mm) | 268mm*58mm*189mm | |
| Weight(kg) | < 3.5Kg | |
