Feature:
Exquisite appearance
Good impact resistance, waterproofing and anticorrosion ability
Full day working
Optimized dimension
High gain, low standing wave, strong anti-interference ability
Endow them with high rot and wind resistibility;
Reduce high-frequency core loss, high efficiency, directivity homogeneity, high power endurance.
Wi-Fi system
| Frequency range | 1710-1880MHz | 1850-1990MHz | 1920-2170MHz |
| VSWR | <1.5 | ||
| Input impendence | 50Ω | ||
| Gain | 6dBi/ 8dBi/ 10dBi/ 12dBi | ||
| Polarization type | Vertical polarization | ||
| Max power | 100W | ||
| Connector type | N female or customized | ||
| Weight | 0.5kg/ 0.8kg/ 1kg/ 2kg | ||
| Dimension | 0.8m/ 0.9m/ 1m/ 1.5m | ||
| Rated Wind Velocity | 60-m/s | ||
| Mounting Kits | U bolts | ||
| Temperature | -40ºC~+55ºC | ||
