Product Feature
* Wide band and high gain.
* Eelegant appearance, simple installation, stable performance.
* Good performance in anti-vibration and resistant to aging.
* Can be installed indoor or outdoor pole mount.
Electrical Specifications |
|
| Frequency range(MHz) | 698~960/1710~2700 |
| Bandwidth(MHz) | 262/990 |
| Gain(dBi) | 10/11 |
| Half-power beam width(°) | H:65/50 V:55/40 |
| VSWR | ≤1.8 |
| Input Impedance(Ω) | 50 |
| Polarization | Vertical |
| Maximum input power(W) | 50 |
| Lightning protection | DC Ground |
| Input connector type | N Female |
| Mechanical Specifications | |
| Dimensions (mm) | 445*210*65 |
| Antenna weight(kg) | 0.91 |
| Operating temperature(°c) | -40~60 |
| Rated Wind Velocity(m/s) | 60 |
| Radome material | ABS |
| Radome color | white |
| Mounting hardware(mm) | 35-50 |
