Feature:
High gain
Full day working
Optimized dimension
Polarization:Vertical or horizontal
Application:
LTE/CDMA/GSM system
Wireless communication and data transmission system
Electrical Specifications |
|
| Frequency range(MHz) | 698~960 |
| Polarization | Vertical |
| Gain(dBi) | 15 |
| Half-power beam width(°) | H:90 V:10 |
| Front-to-back ratio(dB) | ≥23 |
| Input Impedance(Ω) | 50 |
| VSWR | ≤1.5 |
| Sidelobe suppression for first sidelobe above horizon | 15 dB |
| Maximum input power(W) | 400 |
| Lightning protection | DC Ground |
| Mechanical Specifications | |
| Input connector type | N Female |
| Dimensions-mm (Height/Width/Depth) | 2000*280*125 |
| Packing size(mm) | 2050*320*210 |
| Antenna weight (kg) | 13.5 |
| Radome material | UPVC |
| Radome color | Gray |
| Mechanical tilt(°) | 0~10 |
| Operating temperature(°c) | -40~60 |
| Rated Wind Velocity(m/s) | 60 |
| Mounting hardware(mm) | c35~c90 |
