Passive Detection : Able to identify UAV such as DJI and AUTEL that use OFDM high-definition image transmission; Can detect FPV using analog image transmission within 300MHz-6200MHz.
Sound and light alarm: headphone sound alarm, external sound and light alarm.
Log recording: It has alarm log recording and can export alarm logs through USB interface.
Headphone function: capable of obtaining alarm sound through headphones. Firmware upgrade function: Upgrade firmware through USB interface.
Data transmission function: Real time alarm data of the drone can be obtained through the USB port.
Multi language switching: supports English and Russian Language;
Work status display: language, battery level
Working modes: default mode, key frequency band scanning mode, user-defined feature library scanning mode.
Custom detection: Users can modify, delete, or add detection drone feature libraries through the USB interface.
3、Features
1.Drone/Mini-Micro UAV and Remote Controller detection and identification supported by Threat Library.
2.Fixed site configuration for the protection of critical facilities, borders, private and governmentfacilities, airports, etc.
3.Ability to work at night, in foggy and bad weather conditions with its RF detection technology
4.Easy to use with user friendly interface8.Ability to simultaneously detect multiple threats (swarms) from different sectors controlled atdifferent frequencies MlL-STD-810 compliant
The detection range of system is up to 1500 (a thousand) meters.
9.Detection range may varyaccording to level of signals to be detected and existence of obstacles in the environment.
Receiving frequency range: 300MHz-6200MHz
Identification type: OFDM high-definition image transmission signal, FPV FM analog image transmission
Detection distance: 800 - 1.5km
Detection sensitivity: better than -96dBm
Alarm detection methods: headphones, sound and light
Log recording: Supports no less than 500 alarm records
Upgrade and data export interface: mirco USB
