Product Feature
1. Wide Frequecncy Range
2. Low Insertion Loss
3. Low VSWR
4. Excellent Couping Flatness
5. Multiple-Band Frequency Ranges Tetra, Cellular, UMTS and LTE, etc.
6. Minimal RF Insertion Loss.
7. High Reliability.
Applications:
1. Mobile Communication Network Optimization and Indoor distribution system
2. Cluster Communication, Satellite Communication, Shortwave Communication and Hopping Radio
| NO. | Project Name | Unit | GW-MC8025 | |
| 1 | Frequency Range | MHz | 800-2500 | |
| 2 | Isolation | dB | On Coupling≤15 dB ,Isolation ≥20dB; On Coupling>15 dB ,Isolation ≥20dB; |
|
| 3 | Insertion loss | dB | ≤2.1 | Coupling:5±0.6 |
| ≤1.9 | Coupling:6±0.7 | |||
| ≤1.5 | Coupling:7±0.7 | |||
| ≤0.9 | Coupling:10±0.9 | |||
| ≤0.9 | Coupling:12±0.9 | |||
| ≤0.6 | Coupling:15±1.2 | |||
| ≤0.3 | Coupling:20±1.2 | |||
| ≤0.2 | Coupling:25±1.5 | |||
| ≤0.2 | Coupling:30±2 | |||
| ≤0.2 | Coupling:40±2 | |||
| 4 | VSWR | ≤1.3 | ||
| 5 | Power | W | 30 | |
| 6 | Temperature | 'C | -20~+60 | |
| 7 | Connectors | N-F | ||
| 8 | Outline Size | mm | 84*26*17 | |
