Feature:
Exquisite appearance
Good impact resistance, waterproofing and anticorrosion ability
Full day working
Optimized dimension
High gain, low standing wave, strong anti-interference ability
Application:
2.3/2.7 GHz WLAN system
Point-to-multipoint system
Public wireless hot spot coverage
Wi-Fi system
Electrical Specifications |
|
| Frequency range(MHz) | 2300~2700 |
| Bandwidth(MHz) | 400 |
| Gain(dBi) | 10 |
| Half-power beam width(°) | H:360 V:10 |
| VSWR | ≤1.6 |
| Input Impedance(Ω) | 50 |
| Polarization | Vertical |
| Maximum input power(W) | 100 |
| Lightning protection | DC Ground |
| Input connector type | N Female or Requested |
| Mechanical Specifications | |
| Dimensions (mm) | Φ20*770 |
| Antenna weight(kg) | 0.45 |
| Operating temperature(°c) | -40~60 |
| Rated Wind Velocity(m/s) | 60 |
| Radome color | Gray |
| Mounting way | Pole-holding |
| Mounting hardware(mm) | c35-c50 |
