Product Feature
* Elegant appearance, simple installation, stable performance.
* Good performance in anti-vibration and resistant to aging.
* Fit for installation for Aluminum ceiling and Gypsum Ceiling.
| ELECTRICAL | |
| Frequency Range | 698-960/1710-2700-MHz |
| Bandwidth | 262/990-MHz |
| Gain | 7-dBi |
| Intermodulation IM3 | ≤-107-dBm (2W) |
| VSWR | ≤2.0 |
| Polarization | Vertical |
| Max power | 100 -W |
| Nominal Impedance | 50 -Ω |
| MECHANICAL | |
| Connector | N female or customized |
| Antenna Dimension | 208*178*45-mm |
| Weight | 0.5-kg |
| Rated Wind Velocity | 60-m/s |
| Mounting | Wall Mount |
