| █Electrical Specifications | |
| FrequencyRange |
350-400/400-450/450-500/500-560 700-775/775-850/850-930/930-1020 |
| Gain(dBi) |
4-6±1dBi |
| VSWR |
≤2.0 |
| perpendicularPolarization |
8*Vertical/Horizontal |
| Horizontal Beamwidth(0º) Vertical Beamwidth(0º) |
75±10°/45±5°/ 32±3° 65±10°/35±5°/16±3° |
|
Front-to-back ratio(dB) |
≥15/≥18/≥20/≥23 |
| Input Impedance(Ω) | 50Ω |
| Maximum input power(W) | 50W |
| Inpur connector type | N-Female |
| Lightning Protection | DC Ground |
| █Mechanical Specifications | |
| Dimensionsmm(Height/Width/Depth) |
820*390*50mm |
| Packing size(mm) |
830*410*180mm |
| Antenna weight(kg) |
4.5±0.3Kg |
| Operational Humidity(%) | 10-95 |
| Radome Color | White/Black(Or customized green) |
| Operating temperature(ºC) | -30~65º |
| Installution Method |
Handheld |
