1. summary
The portable UAV detector adopts a low-power design and highly integrated design, and is capable of detecting mainstream rotary wing drones such as DJI and AUTEL that use OFDM high-definition image transmission, as well as various DIY crossings that use analog image transmission signals. The device adopts dual antennas and multi- channel simultaneous scanning, which has the characteristics of fast detection speed, high detection sensitivity, long detection distance, low false alarm rate, strong scalability, and easy use.
2. Technical indicators
Receiving frequency range: 300MHz-6200MHz
Identification type: OFDM high-definition image transmission signal, time traveling machine FM analog image transmission
Detection distance: ≥ 1km
Detection sensitivity: better than -96dBm
Alarm detection methods: headphones, sound and light Log recording: Supports no less than 500 alarm records Upgrade and data export interface: mircoUSB
Power supply: Removable lithium battery (type-c charging)
Battery type: 2400mA lithium battery Battery life: ≥ 6 hours (single battery)
Structural dimensions: ≤ 135mm × 60mm × 35mm (host without antenna) Working weight: ≤ 500g (including single battery)
