BP1C is a portable detection system with comprehensive drone surveillance capabilities. It monitors the S/N code, model, coordinates (longitude, latitude, altitude), speed, home point, flight path, controller coordinates(longitude, latitude) and other information of drones within its range through data mining and deep analysis of drone signals.
|
Number |
Index |
Parameter |
Notes |
|
1 |
Detection and identification of drone types |
DJI series drones, FPVs, Xiaomi, Yuneec, Hubsan, Powervision, Tello drones etc. |
|
|
2 |
Localizable drone models |
DJI mavic、air、mini、FPV、avata, etc. |
|
|
3 |
Detection frequency band |
433MHz、900MHz、1.2GHz、1.4GHz、 2.4GHz、5.2GHz、5.8GHz |
|
|
4 |
Detection and positioning distance |
1~10km |
Depending on the environment |
|
5 |
Detection height |
0m~1000m |
|
|
6 |
Number of targets that can be detected simultaneously |
≥5 sorties |
|
|
7 |
Capable of simultaneously tracking and displaying drone trajectories |
≥5strip |
|
|
8 |
Azimuth error |
≤1.5°（RMS） |
|
|
9 |
Positioning accuracy |
≤10m |
|
|
10 |
Detection success rate |
≥95% |
|
|
11 |
Identify response time |
≤5s |
|
