Introduction:
1. 6 modules and Any ruin on the modules never interfere the normal operating for other modules.
2. Pelican case, shockproof and drop-resistance, available for the vehicle running in a worse field environment.
3. Device body is no more than 40kg.
4. Continuously and simultaneously interference to the common used Remote and Phone signals.
Jammer Applications:
Applications:
Sensitive Areas
Prisons
Oil Refineries
Military Bases
Protected Areas
Function:
Effective interference with Remote-Control Signal , Phone signal, 2400MHz Wifi signal transmission.
|
Output interface |
Description |
RF output power(±1.5dBm) |
Antenna |
|
|
CH1 |
433MHz |
47dBm (50W) |
Omni Antenna |
|
|
CH2 |
860-930MHz |
47dBm (50W) |
Omni Antenna |
|
|
CH3 |
1170-1280MHz |
47dBm (50W) |
Omni Antenna |
|
|
CH4 |
2400-2500MHz |
50dBm (100W) |
Omni Antenna |
|
|
CH5 |
1560-1620MHz |
47dBm (50W) |
Omni Antenna |
|
|
CH6 |
5725-5850MHz |
47dBm (50W) |
Omni Antenna |
|
|
Power supply: AC220V |
||||
|
Total Output Power: 350Watt |
||||
|
Frequency Range: 20-6000MHz |
||||
|
Power consumption: 800Watt |
||||
|
Gross Weight: 45Kg |
||||
|
Humidity: up to 80% |
||||
|
Running Temperature: -20℃ to +65℃ |
||||
|
Jammer Module Number |
6 |
|||
|
Jamming Band |
6 bands |
|||
|
Cooling System |
4 Cooling Fans |
|||
|
System Protection |
VSWR, Over-voltage, Over-current |
|||
|
Jamming Source |
Noise Technology |
|||
|
Antenna Type |
High Gain Omni and directional Antennas |
|||
|
Number of Antennas |
6 |
|||
